Shenzhen hardware industry, stamping mold name

On the mode: the upper die is the entire upper half of the Deputy dies, that is installed on the die portion of the press slide .
The upper die: on the mold base is part of the top plate of the upper die and the workpiece close to the press slider, and through the handle or directly fixed to the press slide.
Under the model: the lower die is whole Vice bottom half of the die, installed in the
mold presses on a countertop mold parts terminology : the upper die is the upper half of the entire deputy dies, that is installed in the press the slider on the die part .
The upper die: on the mold base is part of the top plate of the upper die and the workpiece close to the press slider, and through the handle or directly fixed to the press slide.
Under the model: under the model is the lower half of the whole vice die, that is installed on die part of the presses on a countertop.
The lower die: the lower die plate parts of the underside of the lower die, and work directly fixed in the press a work surface or plate.
Edge of the wall: Blade wall blanking the die hole edge of the sidewall.
Edge gradient: edge slope is the slope of blanking the die hole on each side of the blade wall.
Cushion: cushion of compressed air as the driving force behind the bomb top device.
Anti side briquetting: the anti-side of the briquette is part of the support from the other side of the face-way by the force of the punch.
Guide sleeve: the guide sleeve for the relative movement of the lower die to provide precision-oriented tubular parts, using the majority fixed on the mold base, in conjunction with the fixed lower die guide post.
Guide: the guide plate with the plate with the hole punch precision sliding parts, used to guarantee the mutual alignment of the punch and die, and from the discharge (cases) role.
Guide post: guide pin is on the lower die relative movement of the cylindrical part of the precision-oriented, most of the fixed lower die holder and fixed with the die holder guide.
The guide pin is: the guide pin is inserted into the material hole in the guide is its position within the die pin-shaped parts.
Mode guides: guides mode: formwork is based on the guide plate oriented die mold use the punch out of the guide plate.
The guide plate: the guide plate to guide the bar (with volume) material into the die plate oriented parts.
Pillar frame: the pillar frame guide post, guide sleeve mutual sliding mold.
Die: die is mounted on the press for the production of red technology and equipment, coordination of two parts.
Punch: punch, die from the direct formation of the convex parts, stamping the role of the shape of the parts of the work surface.
The die: the die is to die from the direct formation concave parts, stamping the role of within-shaped parts of the work surface.
Shield: shield to prevent fingers or foreign matter into the die plate parts of the danger zone.
The pressure plate (circle): pressure plate (circle) is used to suppress die stamping material or process parts in order to control the material flow of parts, drawing die, most of the pressure plate called a binder ring.
Binder tendons: the tendons of the binder is drawing die or drawing die to control the material flow of the tendon-like protuberances binder tendons can be the local structure of the die or ring binder, it can be set into the concave mold or pressure material circle of separate parts.
Binder threshold: the threshold of the binder is a binder reinforcement of cross-section is rectangular, said special.
By order of the plate: the order of the plate is used for lengthening the die plate parts of the flat support stamping materials.
Flank: Flank in the article (with volume) material side cut out the punch of the feeding location gap.
Side of the plate: side plate (with, volume) material side of the spring to exert pressure, prompting the other side of the tight * guide plate and the plate parts.
Ejector: ejector is a rod-shaped parts up action, directly or indirectly, to the top and labor (sequence) or sequence material.
Ring gear: the ring gear is fine blanking of the die or belt into the ring tooth protruding tooth binder board, rather than the separate parts of the local structure of the die or toothed pressure plate.
Limit set: the limit set is used to limit die minimum shut height of the tubular parts, usually set in the outside of the guide post.
Limit column: limit column height limit die smallest closed cylindrical pieces.
Locating pin (board): the locating pin (board) is to ensure that processes parts in the mold parts have the same position, with its different shapes called pins or positioning plate.
Fixed plate: a fixed plate is fixed punch plate parts.
Fixed stripper plate: fixed stripper plate position in the die fixed stripper plate.
Sales of the fixed block material (board): fixed the backgauge sales (board) is fixed in the mold the backgauge off (board).
Unloading parts: the unloading piece device is unloaded off workers from the punch outer surface (sequence) parts of the non-plate parts or devices.
Stripper plate: the stripper plate materials or workmanship (sequence) unloaded from the punch off the stationary or movable plate-shaped parts. The stripper plate is sometimes made one with the guide plate, and play the role of a conducting, still called the stripper plate.
Screw discharge: discharge screw screw suppress discharge board, for restrictions suppress the resting position of the stripper plate.
Scrap cutter: There are two waste cutter. 1 mounted on a drawing flange trimming die to facilitate the clearance of the cutter used to cut off the whole circle of trimming waste. Installed in the press or mold for the will of Article (with volume) like waste and Cutting in order to facilitate clear the cutter.
Beginning to use the material of block off (board): beginning with block material sales (board) is to locate parts for materials starting end sent. Beginning with the backgauge sales (board) are mobile.
Pieces: pieces that put together parts to form a complete female die and punch, stripper plate or fixed board, etc..
Block (board): block (plate) is positioned with the materials sent for by the side of the blade to cut the gap hardened parts, use either single-sided cutting blade suffered in order to balance the side force. Block (board) is generally used in conjunction with the side edge.
The backgauge pin (board): backgauge marketing (board) is the material along the direction taken to locate the part, with its different shapes, called the backgauge off or blocking plate. The backgauge marketing (board) is the sales of the fixed block material (board) activities backgauge sales (board), beginning with the backgauge marketing (board), collectively referred to as
Plate: the plate is between the fixed plate (or die) and the hardened mold base plate parts to reduce the mold base bear compressive stress.
Mold compound: Compound Die press time travel in the same position two or more processes die.
Keep the circle: to keep the circle accommodate and limit the Ball (sub-) location of the ball guide post mold porous tubular parts.
Activities backgauge sales (board): the activities of the backgauge sales (board) is in the mold up and down or left and right the backgauge off (board).
Toothed binder board: toothed binder board is precision die special pressure plate caused by pressure on the material with a ring gear named.
Putter: The putter is down action, directly or indirectly, to launch a rod-shaped part of the work (order) parts or scrap.
Floating mold handle: the floating of the handle, but the center shaft hole on the mold base plane into the point of view of free movement within a certain range of the handle up and down with the mold base while.
Push the board: the push plate is the plate parts of the die or module, introduced directly or indirectly to the downward movement of workers (order) or waste.
Wedge: Wedge is a wedge-shaped parts to change the direction of linear motion in the mold, most of the wedge so that the vertical movement into horizontal movement.
Bouncing the top: the top is installed in the press audience or die holder stamping assist device driven by air pressure, hydraulic, springs, rubber, etc., to provide upward pressure on the roof of the lower die, mandrel and to promote its Move up.
Suppress the stripper plate: suppress the stripper plate by springs, rubber, hydraulic, pneumatic, the role of active discharge board.
